aaline x OG: 18 ga. | Light Edition
REQUEST A QUOTE ➔
OG 18 ga., made in collaboration with OG Architects, incorporates industrial corrugation to interact with light and reflection. Its gentle curve introduces new profiles within aaline’s interior lighting solutions, drawing on the wave-like shape found in metal cladding. This fixture elegantly combines machined hardware with CNC-carved wooden cores housing aaline’s LED technology.
SERIES: OG
MODEL: 18-ga
EDITION: LI
LUMEN OUTPUT + CONSUMPTION:
4’ | Direct: 1058 lm, 19.3 W | Indirect: 635 lm, 38.6 W
6’ | Direct: 1619 lm, 29.4 W | Indirect: 971 lm, 58.8 W
8’ | Direct: 2191 lm, 39.8 W | Indirect: 1315 lm, 79.6 W
Based on 90 CRI, 3000K. Actual output may vary +/- 5%
POWER INPUT: 110-277V AC, 50/60 Hz
OPTICS: Polycarbonate
-
PROFILE
9-1/2"
LENGTH
4’ | Direct: 1058 lm, 19.3 W | Indirect: 2116 lm, 38.6 W
6’ | Direct: 1619 lm, 29.4 W | Indirect: 3238 lm, 58.8 W
8’ | Direct: 2191 lm, 39.8 W | Indirect: 4382 lm, 79.6 WLIGHT DISTRIBUTION
Direct + IndirectPROGRAMMABLE DRIVER ➔
Remote
CIRCUIT
1
2DIMMING
0-10V
TRIAC/ELV
LUTRON Ecosystem
COLOUR TEMPERATURE ➔
2700K
3000K
3500K
Dim-To-Warm [3000K - 1800K] -
CANOPY
SilverCABLE - REMOTE [LOW VOLTAGE]:
Silver
CABLE LENGTH:
5' [Standard]
Custom
MOUNTING OPTIONS - REMOTE ➔
Independent Remote -
REQUEST A QUOTE ➔
OG 18 ga., made in collaboration with OG Architects, incorporates industrial corrugation to interact with light and reflection. Its gentle curve introduces new profiles within aaline’s interior lighting solutions, drawing on the wave-like shape found in metal cladding. This fixture elegantly combines machined hardware with CNC-carved wooden cores housing aaline’s LED technology.
SERIES: OG
MODEL: 18-ga
EDITION: LI
LUMEN OUTPUT + CONSUMPTION:
4’ | Direct: 1058 lm, 19.3 W | Indirect: 635 lm, 38.6 W
6’ | Direct: 1619 lm, 29.4 W | Indirect: 971 lm, 58.8 W
8’ | Direct: 2191 lm, 39.8 W | Indirect: 1315 lm, 79.6 W
Based on 90 CRI, 3000K. Actual output may vary +/- 5%
POWER INPUT: 110-277V AC, 50/60 Hz
OPTICS: Polycarbonate
REQUEST A QUOTE ➔
OG 18 ga., made in collaboration with OG Architects, incorporates industrial corrugation to interact with light and reflection. Its gentle curve introduces new profiles within aaline’s interior lighting solutions, drawing on the wave-like shape found in metal cladding. This fixture elegantly combines machined hardware with CNC-carved wooden cores housing aaline’s LED technology.
SERIES: OG
MODEL: 18-ga
EDITION: LI
LUMEN OUTPUT + CONSUMPTION:
4’ | Direct: 1058 lm, 19.3 W | Indirect: 635 lm, 38.6 W
6’ | Direct: 1619 lm, 29.4 W | Indirect: 971 lm, 58.8 W
8’ | Direct: 2191 lm, 39.8 W | Indirect: 1315 lm, 79.6 W
Based on 90 CRI, 3000K. Actual output may vary +/- 5%
POWER INPUT: 110-277V AC, 50/60 Hz
OPTICS: Polycarbonate
MATERIALS + FINISHING
HARDWARE
REFLECTOR CORE
REFLECTOR INTERIOR FINISH
REFLECTOR EXTERIOR FINISH
CABLE COLOUR
