Linear Embedded
CONFIGURE YOUR FIXTURE ➔
LINEAR SERIES BROCHURE ➔
REQUEST A QUOTE ➔
aaline’s Linear Embedded (LW-EB) is the core and engine behind aaline’s high-performance lighting systems. All systems with LW-EB modules are powered by programmable lux/lumens drivers for the most accurate, consistent, and high-efficacy performance. The chip-on-board LED modules are integrated with our robust aluminum heatsink for long life expectancy and 536 lm/ft.
SERIES: LW-EB
MODEL: 01
LUMEN OUTPUT: 536 lm/ft, custom upon request
POWER INPUT: 110-277V AC, 50/60 Hz
CONSUMPTION: 9.6 W/ft
OPTICS: Polycarbonate tube diffuser
CONFIGURE YOUR FIXTURE ➔
LINEAR SERIES BROCHURE ➔
REQUEST A QUOTE ➔
aaline’s Linear Embedded (LW-EB) is the core and engine behind aaline’s high-performance lighting systems. All systems with LW-EB modules are powered by programmable lux/lumens drivers for the most accurate, consistent, and high-efficacy performance. The chip-on-board LED modules are integrated with our robust aluminum heatsink for long life expectancy and 536 lm/ft.
SERIES: LW-EB
MODEL: 01
LUMEN OUTPUT: 536 lm/ft, custom upon request
POWER INPUT: 110-277V AC, 50/60 Hz
CONSUMPTION: 9.6 W/ft
OPTICS: Polycarbonate tube diffuser
CONFIGURE YOUR FIXTURE ➔
LINEAR SERIES BROCHURE ➔
REQUEST A QUOTE ➔
aaline’s Linear Embedded (LW-EB) is the core and engine behind aaline’s high-performance lighting systems. All systems with LW-EB modules are powered by programmable lux/lumens drivers for the most accurate, consistent, and high-efficacy performance. The chip-on-board LED modules are integrated with our robust aluminum heatsink for long life expectancy and 536 lm/ft.
SERIES: LW-EB
MODEL: 01
LUMEN OUTPUT: 536 lm/ft, custom upon request
POWER INPUT: 110-277V AC, 50/60 Hz
CONSUMPTION: 9.6 W/ft
OPTICS: Polycarbonate tube diffuser
-
PREMIUM PRODUCT
The LW-EB is a premium system designed to provide a smooth and balanced light distribution with focused output.
CUSTOMIZABLE
LW-EB offers the most upgrades for one product with various specifications to curate your product and custom profiles per request.HIGH-PERFORMANCE TECHNOLOGY
With integrated or remote driver systems as part of our standard collections, aaline can be the kit of parts spec-able in retrofit remodeling or new construction projects.SUSTAINABLE
Our products consist of 100% recyclable fixture components. -
PROFILE
1-3/4"W x 2-1/2"H
LENGTH
Min. 1’ - Max. 8’, Increments of 1’
LIGHT DISTRIBUTION
Direct
Indirect, Min. 3' - Max. 8'
Direct + Indirect, Indirect is 30% of lm/ft
PROGRAMMABLE DRIVER ➔
Integrated
RemoteCIRCUIT
1
2, only available for Direct + Indirect
DIMMING
0-10V
TRIAC/ELV
DALI
LUTRON Ecosystem
COLOUR TEMPERATURE ➔
2700K | Warm White | 90+ CRI
3000K | Soft Warm White | 90+ CRI
3500K | Bright White | 80+ CRI
4000K | Cool White | 90+ CRI -
CANOPY
Black
White
CustomCABLE - INTEGRATED [HIGH VOLTAGE]:
Black
White
CABLE - REMOTE [LOW VOLTAGE]:
Clear Jacket with Silver Core
CABLE LENGTH:
5' [Standard]
Custom
MOUNTING OPTIONS - INTEGRATED ➔
Independent
Junction Box Support
T-Bar Support, for 15/16” t-bar width
MOUNTING OPTIONS - REMOTE ➔
Power Over Cable
T-Bar Support, For 15/16” t-bar width
CANOPY HARDWARE - JUNCTION BOX ONLY
Minimal
Match -
-
Materials + Finishing
SURFACE FINISH
