aaline's integrated "Acoustic + Light" modular system is designed as a tool for architects and designers to tune acoustics with no plastic base material. The system is made with 100% natural felt, backed with sound-absorbent fibre boards. It is one of the best-performing acoustic solutions and the first Zero-Plastic acoustic light with Class A fire rating. Perfect for environmentally low-impact, sustainable architectural projects requiring LEED™ standards, certified projects, and Living Building Challenge.
SERIES: LW-EB
MODEL: 01
UPGRADE: AC
LUMEN OUTPUT: 460 lm/ft, custom upon request
POWER INPUT: 110-277V AC, 50/60 Hz
CONSUMPTION: 10 W/ft
OPTICS: Polycarbonate tube diffuser
CONFIGURE YOUR FIXTURE ➔
LINEAR SERIES BROCHURE ➔
REQUEST A QUOTE ➔
aaline's integrated "Acoustic + Light" modular system is designed as a tool for architects and designers to tune acoustics with no plastic base material. The system is made with 100% natural felt, backed with sound-absorbent fibre boards. It is one of the best-performing acoustic solutions and the first Zero-Plastic acoustic light with Class A fire rating. Perfect for environmentally low-impact, sustainable architectural projects requiring LEED™ standards, certified projects, and Living Building Challenge.
SERIES: LW-EB
MODEL: 01
UPGRADE: AC
LUMEN OUTPUT: 460 lm/ft, custom upon request
POWER INPUT: 110-277V AC, 50/60 Hz
CONSUMPTION: 10 W/ft
OPTICS: Polycarbonate tube diffuser
CONFIGURE YOUR FIXTURE ➔
LINEAR SERIES BROCHURE ➔
REQUEST A QUOTE ➔
aaline's integrated "Acoustic + Light" modular system is designed as a tool for architects and designers to tune acoustics with no plastic base material. The system is made with 100% natural felt, backed with sound-absorbent fibre boards. It is one of the best-performing acoustic solutions and the first Zero-Plastic acoustic light with Class A fire rating. Perfect for environmentally low-impact, sustainable architectural projects requiring LEED™ standards, certified projects, and Living Building Challenge.
SERIES: LW-EB
MODEL: 01
UPGRADE: AC
LUMEN OUTPUT: 460 lm/ft, custom upon request
POWER INPUT: 110-277V AC, 50/60 Hz
CONSUMPTION: 10 W/ft
OPTICS: Polycarbonate tube diffuser
-
SUSTAINABLE
Each piece carved from a single block of FSC certified Canadian hardwood and layered with all-natural felt optional acoustic fiberboard backing to enhance the acoustic performance of the units.CUSTOMIZABLE + MODULAR
Envisioned by Fishtnk’s team, the system is designed as a kit of parts that can be customized and fine-tuned to look and perform exactly as required by the project designers, engineers and architects.SUITABLE PROJECTS
Perfect for environmentally low-impact, sustainable architectural projects in line with LEED™ standards, as well as certified projects and Living Building Challenge. -
PROFILE/DEPTH
6IN: 2-1/8"W x 6"H
12IN: 2-1/8"W x 11-3/8"H
4IN depth is discontinued. For a similar look, see LW-EB-LC-AC Round Edition.
LENGTH
Min. 1’ - Max. 8’, Increments of 1’
LIGHT DISTRIBUTION
Direct
PROGRAMMABLE DRIVER ➔
Integrated
RemoteCIRCUIT
1
DIMMING
0-10V
TRIAC/ELV
DALI
LUTRON Ecosystem
COLOUR TEMPERATURE ➔
2700K | 90+ CRI
3000K | 90+ CRI
3500K | 90+ CRI
4000K | 90+ CRI -
CANOPY
Black
White
CustomCABLE - INTEGRATED [HIGH VOLTAGE]:
Black
White
CABLE - REMOTE [LOW VOLTAGE]:
Clear Jacket with Silver Core
CABLE LENGTH:
5' [Standard]
Custom
MOUNTING OPTIONS - INTEGRATED ➔
Independent
Junction Box Support
T-Bar Support, for 15/16” t-bar width
MOUNTING OPTIONS - REMOTE ➔
Power Over Cable
T-Bar Support, For 15/16” t-bar width
CANOPY HARDWARE - JUNCTION BOX ONLY
Minimal
Match -
-
